ITK® STYLE 211D PTFE Fibres impregnated with heavy PTFE dispersion Product Description ITK® style 211D is braided using Expanded PTFE filaments yarns impregnated with heavy PTFE dispersion, It is a soft, pliable packing easy to compress. The packing combines the advantages of PTFE like excellent chemical resistance, wide temperature range, flexibility and toughness. ITK® style 211D is very effective and adaptable packing with good emergency running properties |
Service Characteristics
|
|
Temperature: -200°C to +280°C
|
pH Range: 0 to 14
|
Rotary Shaft Speed: 7m/s
|
Pressure: 180bar or 2600psi
|
ITK® style 211D can be used in low speed pumps up to 7m/s with wide temperature range against, chemicals, solvents steams etc. They are used extensively in food processing, chemical agricultural and petroleum processing industries.
ITK® STYLE 211L PTFE Braided packing impregnated with heavy PTFE dispersion and lubricated. Product Description ITK® style 211L is square braided packing constructed PTFE filament yarns and impregnated with PTFE dispersio and further heavily lubricated and saturated with an inert lubricant. ITK® style 211L exhibits superior thermal properties, dimensional stability and tensile strength. It is thoroughly impregnated with PTFE in order to enhance the chemical resistance, lubrication and dimensional stability, this helps to ensure even gland local distribution and promoting longer packing life. |
Service Characteristics
|
|
Temperature: -40°C to +280°C
|
pH Range: 2 to 14
|
Rotary Shaft Speed: 13m/s
|
Pressure: 120bar or 1740psi
|
ITK® style 211L can be used in high speed pumps up to 12m/s compared to ITK® style 211D against, chemicals, solvents steams etc. They are used extensively in food processing, chemical agricultural and petroleum processing industries.
ITK® STYLE 211S PTFE Braided packing impregnated with heavy PTFE dispersion and lubricated (Manufactured from FDA compliant materials) Product Description ITK® style 211S is square braided packing constructed PTFE filament yarns and impregnated with PTFE dispersion and further heavily lubricated and saturated with an inert lubricant. ITK® style 211S exhibits superior thermal properties, dimensional stability and tensile strength. It is thoroughly impregnated with PTFE in order to enhance the chemical resistance, lubrication and dimensional stability, this helps to ensure even gland local distribution and promoting longer packing life. ITK® style 211S is solely made from FDA compliant materials and should be specified where Regulatory Compliance packing's are required. |
Service Characteristics
|
|
Temperature: -40°C to +280°C
|
pH Range: 0 to 14
|
Rotary Shaft Speed: 13m/s
|
Pressure: 120bar or 1740psi
|
ITK® style 211S can be used in high speed pumps up to 12m/s compared to ITK® style 211D against, chemicals, solvents, steams etc. They are used extensively in food processing, chemical agricultural and petroleum processing industries.
